| Model |
Nominal(V) |
Capacity |
Certificate |
Other Certificate |
Dimensions |
Spec Sheet |
| UFX102040 |
3.7V |
750mAh |
KC |
UL1642 |
10*20*42mm |
Download |
| UFX102050 |
3.7V |
1000mAh |
KC |
CB/PSE/UL1642/UN38.3/ROHS/CE
|
10*20*52mm |
Download |
| UFX102055 |
3.7v |
1100mAh |
KC |
UL1642 |
|
Download |
| UFX102540 |
3.7V |
1200mAh |
KC |
UL1642(TUV) /CE/CB/UL2054/UM38.3 |
10*25*42mm |
Download |
| UFX103040 |
3.7V |
1200mAh |
KC |
UL1642/CE/PSE/UN38.3/ROHS |
10*30*40mm |
Download |
| UFX103040-3C |
3.7V |
1200mAh |
KC |
UL1642/UL2054/WERCSmart/PSE/BIS |
10*30*42mm |
Download |
| UFX103048 |
3.7V |
1400mAh |
KC |
ROHS/UN38.3/CE/UL1642 |
10*30*50mm |
Download |
| UFX103450 |
3.7V |
1800mAh |
KC |
UN38.3/PSE/ROHS/UL1642/CB
|
10*34*52mm |
Download |
| UFX104050 |
3.7V |
2300mAh |
KC |
CB/UN38.3/ROHS/UL(tuv）1642
|
10*40*52mm |
Download |
| UFX104060 |
3.7V |
2800mAh |
KC |
|
10*40*62mm |
Download |
| UFX104065 |
3.7V |
3200mAh |
KC |
|
10*40*67mm |
Download |
| UFX105050 |
3.7V |
3000mAh |
KC |
UL1642 |
10*50*52mm |
Download |
| UFX105060 |
3.7V |
3500mAh |
KC |
|
10*50*62mm |
Download |
| UFX105065 |
3.7V |
4000mAh |
KC |
|
10*50*67mm |
Download |
| UFX105085 |
3.7V |
5000mAh |
KC |
UL1642/UN38.3
|
10*50*87mm |
Download |
| UFX105573 |
3.7V
|
5000mAh |
KC |
|
10*55*75mm |
Download |
| UFX124040 |
3.7V |
2000mAh |
KC |
EN62133 |
12*40*42mm |
Download |
| UFX124060 |
3.7V |
3600mAh |
KC |
|
12*40*62mm |
Download |
| UFX252040 |
3.7V |
170mAh |
KC |
|
2.5*20*42mm |
Download |
| UFX301525 |
3.7V |
80mAh |
KC |
|
3*15*27mm |
Download |
| UFX303040 |
3.7V |
320mAh |
KC |
|
3*30*42mm |
Download |
| UFX303055 |
3.7V |
500mAh |
KC |
UN38.3/UL1642
|
3*30*57mm |
Download |
| UFX373050 |
3.7V |
550mAh |
KC |
UN38.3 |
3.7*30*52mm |
Download |
| UFX401242 |
3.7V |
100mAh |
KC |
|
4*12*44mm |
Download |
| UFX401120 |
3.7V |
55mAh |
KC |
CB/UL1642/UN38.3
|
4*11*22mm |
Download |
| UFX401230 |
3.7V |
110mAh |
KC |
|
4*12*32mm |
Download |
| UFX401235 |
3.7V |
120mAh
|
KC |
UL1642 |
4*12*37mm |
Download |
| UFX401430 |
3.7V |
120mAh |
KC |
|
4*14*32mm |
Download |
| UFX401430 |
3.7V |
130mAh |
KC |
|
4*14*32mm |
Download |
| UFX402065 |
3.7V |
550mAh |
KC |
|
4*20*67mm |
Download |
| UFX402780 |
3.7V |
1000mAh |
KC |
UL(tuv）1642/ROHS/CB
|
4*27*82mm |
Download |
| UFX402895 |
3.7V |
1200mAh |
KC |
|
4*28*97mm |
Download |
| UFX402934 |
3.7V |
350mAh |
KC |
|
4*29*36mm |
Download |
| UFX403441 |
3.7V |
650mAh |
KC |
|
4*34*43mm |
Download |
| UFX501447 |
3.7V |
280mAh |
KC |
UN38.3 |
5*14*49mm |
Download |
| UFX501535 |
3.7V |
200mAh |
KC |
|
5*15*37mm |
|
| UFX502025 |
3.7V |
200mAh |
KC |
UN38.3 |
5*20*27mm |
|
| UFX502030 |
3.7V |
300mAh |
KC |
CE/UL(tuv）1642
|
5*20*32mm |
|
| UFX502535 |
3.7V |
300mAh |
KC |
UN38.3/UL1642
|
5*25*37mm |
|
| UFX502065 |
3.7V |
600mAh |
KC |
UL1642
|
5*20*67mm |
|
| UFX502248 |
3.7V |
500mAh |
KC |
UL1642 |
5*22*50mm |
|
| UFX502530 |
3.7V |
350mAh |
KC |
|
5*25*32mm |
|
| UFX502535 |
3.7V |
400mAh |
KC |
|
5*25*37mm |
|
| UFX502545 |
3.7V |
600mAh |
KC |
|
5*25*47mm |
|
| UFX502728 |
3.7V |
360mAh |
KC |
|
5*27*30mm |
|
| UFX503035 |
3.7V |
500mAh |
KC |
|
5*30*37mm |
|
| UFX503040 |
3.7V |
600mAh |
KC |
|
5*30*42mm |
|
| UFX503048 |
3.7V |
750mAh |
KC |
CB/UN38.3/UL(tuv）1642/ROHS
|
5*30*50mm |
|
| UFX503759 |
3.7V |
1200mAh |
KC |
UL1642/UN38.3/CE/CB
|
5*37*61mm |
|
| UFX504040 |
3.7V |
800mAh |
KC |
|
5*40*42mm |
|
| UFX505050 |
3.7V |
1500mAh |
KC |
|
5*50*52mm |
|
| UFX 505573 |
3.7V |
2500 mAh |
KC |
UL(tuv)1642 |
5*55*75mm |
|
| UFX506090 |
3.7V |
3000 mAh |
KC |
UL1642 |
5*60*92mm |
|
| UFX523450 |
3.7V |
1000 mAh |
KC |
CB/UN38.3/ROHS/UL(tuv)1642/UL(tuv)2054 |
5.2*34*52mm |
|
| UFX552045 |
3.7V |
450mAh |
KC |
|
5.5*20*47mm |
|
| UFX601535 |
3.7V |
250mAh |
KC
|
UN38.3 |
6*15*37mm |
|
| UFX601720 |
3.7V |
150mAh |
KC |
|
6*17*22mm |
|
| UFX602030 |
3.7V
|
300mAh
|
KC
|
UL1642/UN38.3/加洲65/CE/EN62133/ICE62133
|
6*20*32mm |
|
| UFX602035 |
3.7V
|
400mAh
|
KC |
UL1642/UN38.3 |
6*20*37mm |
|
| UFX602040 |
3.7V
|
400mAh
|
KC
|
|
6*20*40mm |
|
| UFX602040 |
3.7V
|
450mAh
|
KC |
|
6*20*47mm |
|
| UFX602047 |
3.7V |
540mAh
|
KC
|
|
6*20*49mm |
|
| UFX602530 |
3.7V
|
450mAh
|
KC
|
CE |
6*25*32mm |
|
| UFX602535 |
3.7V
|
500mAh |
KC
|
IEC62133/UL(tuv)1642 |
6*25*37mm |
|
| UFX603030 |
3.7V
|
500mAh
|
KC
|
UL1642/UN38.3 |
6*30*32mm |
|
| UFX603040 |
3.7V
|
680mAh
|
KC
|
UL1642 |
6*30*42mm |
|
| UFX603048 |
3.7V
|
900mAh
|
KC |
UL1642/UN38.3/IEC62133/CE |
6*30*50mm |
|
| UFX603450 |
3.7V
|
1200mAh
|
KC |
UL1642 |
6*34*52mm |
|
| UFX604050 |
3.7V
|
1500mAh
|
KC
|
UL1642 |
6*40*52mm |
|
| UFX604060 |
3.7V
|
1700mAh
|
KC |
UL1642 |
6*40*62mm |
|
| UFX604070 |
3.7V |
2000mAh
|
KC
|
|
6*40*72mm |
|
| UFX605060 |
3.7V
|
2000mAh
|
KC
|
CB/UN38.3 |
6*50*62mm |
|
| UFX605080 |
3.7V
|
3000mAh
|
KC
|
UL(tuv）1642/UN38.3 |
6*50*82mm |
|
| UFX605473 |
3.7V
|
3000mAh
|
KC
|
|
6*54*75mm |
|
UFX606090
|
3.7V
|
4000mAh
|
KC
|
UL(tuv）1642/ROHS/UN38.3 |
6*60*92mm |
|
| UFX634169 |
3.7V |
2000mAh |
KC
|
|
6.3*41*69mm |
|
UFX641447
|
3.7V |
400mAh
|
KC
|
|
6.4*14*47mm |
|
UFX651725
|
3.7V
|
230mAh
|
KC
|
|
6.5*17*27mm |
|
UFX653040
|
3.7V
|
800mAh
|
KC
|
|
6.5*30*42mm |
|
| UFX654065 |
3.7V |
2000mAh
|
KC
|
UL1642/PSE/UN38.3/CE/CB |
6.5*40*67mm |
|
UFX686770
|
3.7V
|
4000mAh
|
KC
|
|
6.8*67*72mm |
|
UFX701330
|
3.7V
|
200mAh
|
KC
|
ROHS/CE/UN38.3/UL(tuv）1642 |
70*13*32mm |
|
| UFX701488 |
3.7V |
850mAh |
KC |
|
7*14*90mm |
|
UFX701535
|
3.7V
|
350mAh
|
KC
|
UL(tuv）1642/CE/ROHS/UN38.3/IEC62133/PSE |
7*15*37mm |
|
UFX702025
|
3.7V
|
300mAh
|
KC
|
CE/加洲65/UN38.3/EN62133/UL(tuv）1642 |
7*20*27mm |
|
UFX702060
|
3.7V
|
850mAh
|
KC
|
CE |
7*20*62 mm |
|
UFX702248
|
3.7V
|
700mAh
|
KC
|
IEC62133 |
7*22*50mm |
|
UFX702248
|
3.7V
|
800mAh
|
KC
|
|
7*22*50 mm |
|
| UFX702257 |
3.7V
|
1000mAh
|
KC
|
L(tuv）1642/UN38.3 |
7*22*59 mm |
|
UFX703048
|
3.7V
|
1000mAh
|
KC
|
UL1642/CB/ROHS |
7*30*50mm |
|
UFX703440
|
3.7V
|
1000mAh
|
KC
|
|
7*34*50mm |
|
UFX706090
|
3.7V
|
5000mAh
|
KC
|
UL1642 |
7*60*92 mm |
|
UFX721944
|
3.7V
|
630mAh
|
KC |
UL(tuv)1642 |
7.2*19*46 mm |
|
UFX751635
|
3.7V
|
380mAh
|
KC
|
|
7.5*16*37mm |
|
UFX702035
|
3.7V
|
500mAh
|
KC
|
|
7.5*20*37 mm |
|
UFX753450
|
3.7V
|
1300mAh
|
KC
|
UN38.3 |
7.5*34*52 mm |
|
| UFX 756077 |
3.7V |
4800mAh |
KC |
CB/UN38.3/UL1642 |
7.5*60*79 mm |
|
| UFX782150 |
3.7V
|
800mAh
|
KC
|
|
7.8*21*52mm |
|
UFX801350
|
3.7V
|
500mAh
|
KC
|
UL(tuv)1642 |
8*13*52 mm |
|
UFX 801735
|
3.7V
|
500mAh
|
KC
|
UN38.3 |
8*17*37mm |
|
UFX802030
|
3.7V
|
400mAh
|
KC
|
UL1642/PSE |
8*20*32mm |
|
UFX802035
|
3.7V
|
500mAh
|
KC
|
|
8*20*37 mm |
|
UFX802040
|
3.7V
|
600mAh
|
KC
|
UL(tuv）1642/CE/UN38.3 |
8*20*42 mm |
|
| UFX802050 |
3.7V |
800mAh |
KC |
UL(tuv)1642/CB/UN3.83/CE |
8*20*52mm |
|
| UFX802248 |
3.7V |
1000mAh |
KC |
|
8*22*50mm |
|
| UFX802528 |
3.7V |
480mAh |
KC |
UN38.3/CE/IEC62133 |
8*25*30mm |
|
| UFX802528 |
3.7V |
500mAh |
KC |
UL1642/PSE/CB |
8*25*30mm |
|
| UFX802530 |
3.7V |
600mAh |
KC |
UL1642/UL2054/CB |
8*25*32mm |
|
| UFX802535 |
3.7V |
700mAh |
KC |
|
8*25*37mm |
|
| UFX803035 |
3.7V |
800mAh |
KC |
UL(tuv)1642 |
8*30*37mm |
|
| UFX803040 |
3.7V |
900mAh |
KC |
|
8*30*42mm |
|
| UFX803048 |
3.7V |
1200mAh |
KC |
UL(tuv)1642/CB/CE/ROHS |
8*30*50mm |
|
| UFX803448 |
3.7V |
1300 mAh |
KC |
|
8*34*50mm |
|
| UFX803450 |
3.7V |
1500mAh |
KC |
UL1642/CB/ROHS/CE/UN38.3 |
8*34*52mm |
Download |
| UFX804050 |
3.7V |
1800mAh |
KC |
|
8*40*50mm |
|
| UFX804068 |
3.7V |
2500 mAh |
KC |
UL1642 |
8*40*70mm |
|
| UFX805080 |
3.7V |
4000mAh |
KC |
|
8*50*82mm |
|
| UFX832248 |
3.7V |
920mAh |
KC |
UL(tuv)1642/UN38.3/EN62133 |
8.3*22*50mm |
|
| UFX851768 |
3.7V |
850mAh |
KC |
UL(tuv)1642 |
8.5*17*69mm |
|
| UFX901428 |
3.7V |
260mAh |
KC |
CE/CB |
9*14*30mm |
|
| UFX901744 |
3.7V |
680mAh |
KC |
|
9*17*46mm |
|
| UFX902030 |
3.7V |
500mAh |
KC |
UL(tuv)1642/UN38.3/CE |
9*20*32mm |
|
| UFX902035 |
3.7V |
600mAh |
KC |
|
9*20*37mm |
|
| UFX902248 |
3.7V |
1050mAh |
KC |
UN38.3/CE/IEC62133 |
9*22*50mm |
|
| UFX902535 |
3.7V
|
800mAh |
KC |
UL1642 |
9*25*37mm |
|
| UFX903450 |
3.7V |
1600mAh |
KC |
|
9*34*52mm |
|
| UFX951768 |
3.7V |
1200mAh |
KC |
UL(tuv)1642/UN38.3 |
9.5*17*69mm |
|
| UFX955565 |
3.7V |
5000mAh
|
KC |
UL(tuv)1642/UN38.3 |
9.5*55*67mm |
|
| UFX3060100 |
3.7V |
2000mAh
|
KC |
UN38.3/EN62133/GB31241/UL(tuv)1642 |
3*60*100mm |
|
| UFX4027110 |
3.7V |
1000mAh
|
KC |
CB |
4*27*102mm |
|
| UFX6080130 |
3.7V |
8000mAh |
KC |
CB/UL1642/PSE |
6*80*132mm |
|
| UFX9559104 |
3.8V |
8000mAh |
KC |
UN38.3/ROHS/UL1642/GB31241报告/EN62133/CB/BIS |
9.5*59*106mm |
|
| UFX162027-2P |
3.7V |
700mAh |
KC |
ROHS |
16*20*29mm |
|
| UFX502025-4P |
3.7V |
800mAh |
KC |
|
21*20*27mm |
|
| UFX604040-2S |
7.4V |
1000mAh |
KC |
|
13*40*43mm |
|
| UFX102050-2S |
7.4V |
1000mAh |
KC |
|
20*20*53mm |
|
| UFX104050-2S |
7.4V |
2500mAh |
KC |
|
20*40*52mm |
|
| UFX124060-2S |
7.4V |
1700mAh |
KC |
|
12*40*63mm |
|
| UFX503450-2S |
7.4V |
1000mAh |
KC |
CB/ROHS |
10*34*52mm |
|
UFX603030-2S
|
7.4V
|
500mAh
|
KC |
CB |
12*30*32mm |
|
| UFX603450-2S |
7.4V |
1200mAh |
KC |
CB/UN38.3 |
12*34*52mm |
|
| UFX702257-2S |
7.4V |
1000mAh |
KC |
CB/UN38.3 |
14*22*59mm |
|
| UFX804068-2S |
7.4V
|
2500mAh |
KC |
CB |
16*40*70mm |
|
| UFX6067101-3S |
11.1V |
5800 mAh |
KC |
CB/UN38.3/ROHS |
18*67*103mm |
|
| UFX18650-2S2P |
7.4V |
5200mAh |
KC |
|
|
|
| UFX18650-3S |
11.1V |
2600mAh |
KC |
CB/UN38.3 |
|
|
