UFX703060 700mAh 3.2V China LiFeO4 Battery Factory Professional Custom

Item No.: ufx024
UFX703060 700mAh is a type of lithium iron phosphate (LiFePO4) battery that has a nominal voltage of 3.2 volts. More safety, as they are less prone to overheating compared to other types of lithium-ion batteries.
$0.00
/ Pieces
Description Review
Description

Ufine Battery 703060 700mAh 3.2V
Dimension: 7×30×62(mm)

 1

Specs of 703060 700mAh 3.2V

1、Mechanical Characteristics

Cell:

UFX703060

PCM:

Yes

NTC:

No

Weight:

22g

Configuration:

1S1P





2、Electrical Specification

Capacity:

700mAh

Nominal Voltage:

3.2V

Energy:

2.88Wh

Internal Impedance:

less than 150mΩ

Max. Charge Voltage:

3.9V

Discharge Cut Off:

2.2V

Max. Charge Current:

700mA

Max. Discharge Current:

700mA

Standard Charge Current:

350mA

Standard Discharge Current:

350mA

Charge Temp. Range:

10°C to 45°C

Discharge Temp. Range

-20°C to 60°C

Storage Temp. Range

1 year at -20℃ to +30℃

 Cycle life:

100 cycles ≥92%

3 moths at -20℃ to +45℃

300 cycles ≥88%

1 month at -20℃ to +60℃

500 cycles ≥80%

 3、Cell protection

Overcharge Detection :

4.28 ±25mV (0.7to 1.3sec delay, release 4.08V ±50mV)

Overdischarge Detection:

2.9V ±80mV (70 to 150msec. delay, release 3.0V ±100mV)

Overcurrent Detection:

 4A to 6A (5to 15msec. delay)

Short protection:

Yes

DISCHARGE RATE CHARACTERISTICS                                                          CYCLE LIFE CHARACTERISTICS


Product Details

Ufine is a manufacturer  with independent research and development and production of polymer lithium-ion batteries. With years of experience in the field of polymer lithium-ion battery solutions, We have accumulated rich  technical experience. Currently, the company offers more than 300 different product models, all certified with KC, UL, CB, and other certifications.Moreover, We can quickly design and develop new products according to customer needs and arrange sample testing.

Why Choose Ufine to OEM or ODM Battery

UFine battery has over 30 professional engineers and technical staff who can provide polymer lithium battery solutions for you. As a lithium battery manufacturer, we are capable of rapid design, customization, and bulk production. Here are the main characteristics of our company:
1、Source manufacturer, strong factory, and powerful design and development capabilities.
2、
Short delivery time and sufficient inventory.

3、Self-produced, sufficient capacity, refuse false labeling, and guarantee capacity.
4、Strict quality control through a full range of quality systems from raw materials to finished products.
5、Our products are certified and meet various international battery standards, allowing us to directly export to markets such as Europe, America, and Korea.
6、Our team of professional foreign trade sales engineers can quickly respond to customer inquiries and provide solutions
  • High energy density
  • Long cycle life
  • Capability of discharge at ultra-low temperature of -40℃
  • Ability to be designed for high voltage (up to 4.4V)
  • Customizable sample and mass production according to customer needs.
Factory Photos

Display Of Testing Equipment


Certification
